Mini Industrial Computer Full Gigabit Soft Router ndustrial Control Fanless Embedded
Mini Industrial Computer Full Gigabit Soft Router ndustrial Control Fanless Embedded
Regular price
¥1,335.00 CNY
Regular price
Sale price
¥1,335.00 CNY
Unit price
per
Couldn't load pickup availability
Host characteristics：
Intel Sky Lake-U/Kirby Lake-U platform processor
Graphics card Intel HD core graphics card 510/520/610/620
Display interface 1 * VGA interface
1 * HDMI 1.4, maximum resolution 4096X2304@24Hz
Memory 1 * DDR4 SO-DIMM, supports up to 32GB DDR4/2133MT/s
Network 6 * Intel i211AT, supports network wake-up and network card startup
Storage 1 * SATA3.0 interface
1 * mPCIe, supports mSATA SSD
Expansion slot 1 * mPCIe, supports WIFI/4G/3G Module
1 * SIM card slot
Rear I/O interface 1 * DC-IN interface
1 * Power indicator light+hard drive indicator light
6 * RJ45 interface
Front I/O interface 1 * switch button
1 * IO button
1 * VGA interface
1 * HDMI interface
4 * USB 3.0 interface
1 * RJ45 COM interface
BIOS Supply AMI UEFI BIOS
Power Supply DC 12V
Operating System Windows 10/11/Linux
No fan for heat dissipation
Working temperature -10 ℃~60 ℃
Storage temperature -20 ℃~70 ℃
Humidity 5% -95% relative humidity, no condensation
Size 215 * 110 * 53mm
